Safe-R

SR/ST

Soffit

SR/ST

Safe-R Soffit board provides effective thermal and fire performance solutions in structural ceiling applications in commercial and residential buildings. This high performance phenolic insulation board is faced with low emissivity foil facings.

Safe-R Soffit Board is supplied as a performance, rather than decorative product. Refer to Safe-R Soffit Plus, a high performance laminate that offers low maintenance and security protection with a surface that will accept a decorative finish.

Enquire about this product

Attributes

Product Details
Product name	SR/ST
Material code	Please refer to our packing list
Type	Phenolic Insulation
Application	Soffit
Thickness	50mm, 60mm, 75mm, 80mm, 100mm, 120mm
Inner facing	composite foil facings
Outer facing	composite foil facings
Thermal conductivity	0.020 – 0.021 (W/mK)
Compressive strength	CS (10\Y) 100
Unit of measurement	mm
Size/Dimensions	2400 X 1200mm
Reaction to fire	Euroclass C s1 d0
Installation guidelines	Please refer to marketing materials
EPD	An Environmental Product Declaration (EPD), certified by IGBC is available for this product. Please contact technical support for further details.

Typical U-Values

Table 1
U-Value calculations to EN ISO:6946

SR/ST Insulation for Soffit Application

Build-up

200mm Concrete Soffit
SR/ST

Thickness	50	60	75	80	100	120
U Value	0.37	0.32	0.26	0.25	0.19	0.16

200mm concrete

SR/ST

Key Points

Phenolic Insulation

Euroclass C-s1 d0 Fire Classification

Thermal Conductivity as Low as 0.020 W/Mk

Reduced Thermal Bridging
