XPS

XPS 500

Extruded Polystyrene

XPS 500

XPS 500 is a high performance rigid extruded polystyrene insulation board providing a durable thermal solution to technically demanding applications where high compressive loading is a requirement. XPS 500 is ideally suited for use in commercial, industrial and cold storage areas where vehicular traffic and loading is an issue.

Enquire about this product

XPS 300, a high performance rigid extruded polystyrene insulation board

Attributes

Product Details
Product name	XPS 500
Material code	Please refer to packing list
Type	High Performance Extruded Polystyrene Insulation
Thickness	50mm, 60mm, 80mm, 100mm, 120mm
Inner facing	N/A
Outer facing	N/A
Thermal Conductivity	0.033 – 0.035 (W/Mk)
Compressive strength	CS (10\Y) 500
Unit of measurement	mm
Size/Dimensions	1250 x 600mm
Reaction to fire	Euroclass E
Installation guidelines	Please refer to marketing materials

Thermal Resistances

Thickness (mm)	R-Value (m2K/W)
30	0.90
40*	1.20
50	1.50
60	1.80
80	2.25
100	2.85
120	3.40

*Available subject to quantity and lead time

Key Points

Ideally suited for use in highly loaded and trafficked floors, basement walls and inverted roofs

High Performance rigid extruded polystryrene

Available in 300 kPA, 500 kPA and 700 kPA

Call our Technical Team today 046 906 6050
