ECO360 MA (Floors)

ECO360

ECO/MA (FLOORS)

Bio-enhanced, superior performance PIR insulation suitable for solid and suspended floors. ECO360 MA for floors offers excellent insulation performance with a thermal conductivity of 0.020 W/mK.

This bio-enhanced insulation will significantly improve the U-Value of new and existing floors. It is lightweight, easy to install and combines high compressive strength with low thermal conductivity, providing a high performance solution for floor insulation.

ECO360 MA is halogen free and the product packaging is bio-degradable while the overall packaging content has been reduced significantly.

Benefits

Specification Clause

The floor insulation shall be ECO360 MA Floors manufactured to EN 13165 by Unilin Insulation, comprising a rigid modified Polyisocyanurate (PIR) core with textured robust low emissivity foil facings. The ECO360 MA_ _ mm with a declared Lambda value as low as 0.020 W/mK to achieve a U value of _ _ _W/m2K for the floor element. To be installed in accordance with instructions issued by Unilin Insulation

Refer to NBS clause M10 290, M10 40, M13 260 M13 40.

1. Good detailing at the wall/floor junction is essential in reducing Thermal Bridging. By placing an upstand of Unilin Perimeter Strip (XO/STR at 0.021 W/mK) insulation with a minimum 25mm thickness around the external and internal wall/floor junctions, a robust detail is created.

2. ECO360 MA is lightweight and suitable for use with underfloor heating. Thanks to its thickness to performance ratio, it allows for reduced insulation thickness. The boards should be laid with closely butted joints, laid staggered with a break bonded pattern and fitted tightly at edges and around any service penetrations.

Note: This product has the strength and thermal properties required to reach the high performance U-Values specified in the Building Regulations.
